Galvanized Steel Stamping Parts
Pre-coated galvanized steel stamped parts with built-in corrosion protection for outdoor and humid environment applications.
* Actual product photos — only background processed
Power Supply Box / Enclosure
Galvanized steel (SECC) power supply enclosure with precision-stamped mounting holes, ventilation slots and snap-fit features. Built-in zinc coating provides excellent corrosion resistance for electrical and industrial applications.
Key Features:
✦ Multi-hole pattern for component mounting
✦ Snap-fit features & card slots for assembly
✦ SECC electrolytic galvanized steel
✦ Thickness: 0.5–2.0mm
✦ Tolerance: ±0.05mm
✦ Surface: Zinc coated (standard)
* Actual product photos — only background processed
Automotive Fan Bracket Assembly
Multi-component galvanized steel fan bracket assembly for automotive engine bay applications. 20 rivets integrate 4 sub-assemblies into one unit — a stamped housing, 5 internal baffles, 2 rubber handles, and 1 additional stamped component — demonstrating full stamping-to-assembly capability.
Assembly Breakdown:
① Stamped outer housing with ventilation slots
② 5 internal baffles for airflow channeling
③ 2 rubber handles (vibration-dampened grip)
④ 1 auxiliary stamped component
Process & Specs:
✦ 20 rivets for structural integration
✦ GI / SECC galvanized steel
✦ Thickness: 0.8–3.0mm | Tolerance: ±0.05mm
✦ Full service: stamping → riveting → assembly
Available Grades
Common Applications
- ▸ Outdoor enclosures & cabinets
- ▸ HVAC ducting & components
- ▸ Automotive under-hood brackets
- ▸ Fencing & gate hardware
- ▸ Roofing & building components
⚙️ Our Capabilities
0.3–6.0mm thickness | ±0.05mm tolerance | Z275 coating standard
Ready to start your project? Get a free quote today.
